Specification of hot stamping plastic storage box
| Specifications | |
| Item name | Hot stamping film for plastic storage box |
| Usage | For plastic storage box |
| Material type | Film |
| Method | Heat transfer printing |
| Material | ABS/EVA/PET |
| Brand name | YiXin |
| MOQ | 800 square meters |
| Thickness | 0.02~0.025mm |
| Maximum colors | 10 |
| Maximum printing area | 900*620mm |
| production time | 10~15 days |
| shipping | by ocean |
Steps about Films production
1. Artwork we will make an layout design for you ,according to your given draft design and product detail
↓
2.Confirm the artwork After you confirm the final design then we will start for the plate making
↓
3.Plate making It takes about 7~8 days
↓
4.Film printing Print in big rolls →drying → cut into small rolls →quality check
It takes about 4-5 days
↓
5.Packaging Polybag+drying agent+carton
↓
6. Delivery By express, by Sea, or by air →It's up to you
The struct of heat transfer film
Heat transfer film is a special printing functional film with patterns or words, on the same affection of temperature and pressure,the film will fall out with base layer.
Heat trasnsfer film always consist of 3~4 layers.3 layers are consist of carrier layer,oil layer and glue layer.Four layers are contain carrier layer,base layer,oil layer and glue layer.
Following message are the details about this four layers,
Carrier layer:the carrier of base layer,oil layer and glue layer(the usual material is PET),it satisfied with high temperature resistance,pressure resistance and small tensile deformation.
Base layer: A layer of mold release, always stay solid state under normal temperature,but will fusion when it is on ordered temperature, adhesion become lower and fall out from carrier layer.Release layer is the key of transfer print on printing stock and finish the depart from oil layer.It need good wear resistance,has function on protect colourful oil, lower the radiation intensity, lower the destroy of oil from air, extend the shelflife of oil and buffer adhesion between substrate film and oil layer.
Oil layer:This layer is the basic of printing quality.Heat transfer film is printing patterns by gravure printing,so it can show vivid picture and lively colour, it's pattern also has strong restore function. It can make your products packing more perfect.
Glue layer:High adhesion with surface of printing stock is the basic function, to ensure fastness of printing stock and printing layer.Glue in this layer must match with printing materials.(Such as ABS/PP/PE/Metal/EVA,they need match with different kinds of glue.Different kinds of glue have different adhesion intension.)
Heat transfer printing plastic storage box
There are too many goods in our house, even sometimes we can't find the one we need,so a storage box is popular in this time.Heat transfer printing is a better choose for storage box to choose for printing on their products.It is in vivid picture and live colours.The pictures will be wear resisitance after heat transfer printing.
Heat transfer film
Heat transfer film is a special printing functional film with patterns or words, on the same affection of temperature and pressure,the film will fall out with base layer.
Heat trasnsfer film always consist of 3~4 layers.3 layers are consist of carrier layer,oil layer and glue layer.Four layers are contain carrier layer,base layer,oil layer and glue layer.
Aeon Printing Materials Co,.Ltd
Aeon Printing Materials Co.,LTD was established in 1999.After recent 10 years development in
heat transfer printing,we have become more proficient in our technology, and our business has already covered all parts in China,which has big influence in same industry. Really hope to develop good business relationship as well as friendship with you!
